Here we go, another year passed. So a Happy New Year to you all, I thought It was time for some stats so here goes:

- 41 entries posted
- most popular articles were about my Samsung Galaxy SII and secret codes and cyanogen
- visits steadily increased from 2000 to 10000 every month throughout the year
- The top 3 visitors respectively are US, UK then France

So thanks for your support and I’ll try to post more and intersting stuff this year

I have been working on Graphite for a while and the one thing I didn’t like much was having to use Apache. It took some time to get it right, but I have eventually set it up to use supervisor, uwsgi and nginx. I have installed graphite 0.9.9 from sources. This setup is on a Debian stable system. First things first, a few packages to install: apt-get install python-dev libxml2-dev build-essential python-django-tagging. Then unpack carbon, whisper and graphite-web in that order and install them (default directory is /opt/graphite).

Then you need to grab uwsgi and unpack it and cd into the directory, you are now required to run this:

wget http://projects.unbit.it/downloads/uwsgi-0.9.9.2.tar.gz
tar xf uwsgi-0.9.9.2.tar.gz
cd uwsgi-0.9.9.2
make -f Makefile.Py26
cp uwsgi /usr/local/bin/
cp nginx/uwsgi_params /etc/nginx/

All is well in the universe, it is time to configure supervisor (apt-get install supervisor). Then create a file called /etc/supervisor/conf.d/uwsgi.conf and put that in. To restart supervisor, make sure you do a stop/start. Restart is flaky for me.

[program:uwsgi]
command=/usr/local/bin/uwsgi
  --module 'django.core.handlers.wsgi:WSGIHandler()'
  --socket 127.0.0.1:3031
  --chdir /opt/graphite/webapp
  --processes 1
  --master
  --harakiri 120
  --max-requests 5000
  --pythonpath "['/opt/graphite/webapp'] + sys.path"
directory=/opt/graphite/webapp
environment=DJANGO_SETTINGS_MODULE='graphite.settings'
user=www-data
autostart=true
autorestart=true
stdout_logfile=/var/log/nginx/uwsgi.log
redirect_stderr=true
stopsignal=QUIT

Next is to get your nginx config right, keep in mind that i use a directory within a vhost for graphite, so your config will differ if you use graphite as /, here is my full config:

server {
        listen 80;
        listen [::]:80; # use this only if using IPv6
        client_max_body_size    4M;
        server_name  graphite.frlinux.net;
        root   /var/www/stats;
        access_log  /var/log/nginx/stats.access.log;
        error_log  /var/log/nginx/stats.error.log;

        location / {
        }
       location /graphite/ {
                gzip off;
                include uwsgi_params;
                uwsgi_pass      127.0.0.1:3031;
        }
       location /content {
                alias /opt/graphite/webapp/graphite/content;
                gzip off;
                include uwsgi_params;
                uwsgi_pass      127.0.0.1:3031;
        }
       location /metrics {
                alias /opt/graphite/webapp/graphite/metrics;
                gzip off;
                include uwsgi_params;
                uwsgi_pass      127.0.0.1:3031;
        }
       location /dashboard {
                alias /opt/graphite/webapp/graphite/dashboard;
                gzip off;
                include uwsgi_params;
                uwsgi_pass      127.0.0.1:3031;
        }
       location /render {
                alias /opt/graphite/webapp/graphite/render;
                gzip off;
                include uwsgi_params;
                uwsgi_pass      127.0.0.1:3031;
        }
       location /browser {
                alias /opt/graphite/webapp/graphite/browser;
                gzip off;
                include uwsgi_params;
                uwsgi_pass      127.0.0.1:3031;
        }
       location /composer {
                alias /opt/graphite/webapp/graphite/composer;
                gzip off;
                include uwsgi_params;
                uwsgi_pass      127.0.0.1:3031;
        }
}

That’s it, point your browsers to your site like: http://site.example.com/graphite and it should be ready to show you data. Keep in mind that you have to take care of security which I am not covering in this article.

A friend of mine made me aware of a nicer web interface for git than gitweb called cgit. You will need to grab the source and compile it. I am assuming that you use /var/www/ as the root of your web server and fcgiwrap which should be configured right already. This is the missing bits for my config:

       location /cgit/ {
		index cgit.cgi;
		include fastcgi_params;
                gzip off;

               if ($uri ~ "/cgit/cgit.cgi") {
                        fastcgi_pass unix:/var/run/fcgiwrap.socket;
                }

        }

You then need to create a folder called /var/www/cgit in which you copy the cgit binary but also cgit.css and cgit.png. You then need to create a /etc/cgitrc configuration file which you will edit for your local configuration and projects. Mine looks like this:

root=/var/cache/git
repo.url=tripwire
repo.desc=Tripwire
repo.path=/var/cache/git/tripwire/.git

Restart/reload your nginx and you are ready to roll.

I have toyed with this yesterday and thought I would share the experiment. I wanted to try out the OpenVPN software built-in Cyanogen for my Samsung Galaxy S2, for this I used a Debian on the other side (which uses a public IP). The first step is obviously installing OpenVPN on the server, then configuring it. Once this is installed, you can do the following steps, this will take care of symlinking the easy-rsa directory, create the server CA and create its certificates.

ln -s /usr/share/doc/openvpn/examples/easy-rsa/1.0 easy-rsa
cd easy-rsa
source ./vars
./clean-all
./build-ca
./build-dh
./build-key-server yourserver

Once this is done and you have checked there was no error in all the commands you typed, you can create your first client, still within the same directory do: ./build-key-pkcs12 cm7. In this example, cm7 is your client name.

This is the working config for my OpenVPN server, edit /etc/openvpn/server.conf. I chose TCP as a more reliable way to have my client keep the vpn connection over crappy GPRS.

proto tcp
port 8443
dev tun
ca /etc/openvpn/easy-rsa/keys/ca.crt
cert /etc/openvpn/easy-rsa/keys/yourserver.crt
key /etc/openvpn/easy-rsa/keys/yourserver.key
dh /etc/openvpn/easy-rsa/keys/dh1024.pem
ifconfig-pool-persist ipp.txt
server 192.168.6.0 255.255.255.0
keepalive 10 120
persist-key
persist-tun
status /var/log/openvpn-status.log
verb 3
mssfix 1200
tun-mtu 1200

Now comes the interesting bit, Cyanogen has a page on OpenVPN but they don’t really explain how to install the p12 cert you generated. You will need to copy that to the root of your sdcard, then go to Settings/Location and Security/Storage Credentials/Install from SD Card. Once you have selected the file, it will ask for the same password as used during the client cert generation, then you can select a storage password to keep it safe.

You can now set up your OpenVPN, go to Settings/Wireless & Networks/VPN Settings/Add VPN, then define the IP, name and certs, select the same cert for CA and user. Then go to advanced and make sure you change the IP Port and switch to TCP. Now the interesting part, it failed to connect until i rebooted the device. Has to be the shittiest fix ever but here goes…

Make sure you have started your OpenVPN server and check the logs for errors.

I had posted about dnssec a few months ago but that was using some quite cumbersome method to deploy DNS Security to your DNS. I have since looked at OpenDNSSEC which is a more suitable and easier solution. Here are my steps to make it work on Debian.

Big Fat Warning: Test this at your own risk, do not deploy in live setups unless you know what you are doing, this will eat kittens and increase your carbon tax. Still reading? Carry on then.

I am using Debian Wheezy (testing) for this DNS setup because the OpenDNSSEC packages are more up to date. Start off by installing the required packages: apt-get install opendnssec libhsm-bin softhsm libsofthsm libhsm-bin. Then you can start on configuring it. All files are under /etc/opendnssec.

Edit the following file: conf.xml (change your PIN with your own):

<?xml version="1.0" encoding="UTF-8"?>
<!-- $Id: conf.xml.in 3192 2010-04-14 20:51:42Z rb $ -->
<Configuration>
        <RepositoryList>

                <Repository name="SoftHSM">
                        <Module>/usr/lib/libsofthsm.so</Module>
                        <TokenLabel>OpenDNSSEC</TokenLabel>
                        <PIN>6666</PIN>
                </Repository>
        </RepositoryList>
        <Common>
                <Logging>
                        <Syslog><Facility>local0</Facility></Syslog>
                </Logging>

                <PolicyFile>/etc/opendnssec/kasp.xml</PolicyFile>
                <ZoneListFile>/etc/opendnssec/zonelist.xml</ZoneListFile>
        </Common>
        <Enforcer>
                <Privileges>
                        <User>opendnssec</User>
                        <Group>opendnssec</Group>
                </Privileges>
                <Datastore><SQLite>/var/lib/opendnssec/db/kasp.db</SQLite></Datastore>
                <Interval>PT3600S</Interval>
        </Enforcer>
        <Signer>
                <Privileges>
                        <User>opendnssec</User>
                        <Group>opendnssec</Group>
                </Privileges>
                <WorkingDirectory>/var/lib/opendnssec/tmp</WorkingDirectory>
                <WorkerThreads>2</WorkerThreads>
                <NotifyCommand>/usr/sbin/rndc reload %zone</NotifyCommand>
        </Signer>
        <Auditor>
                <Privileges>
                        <User>opendnssec</User>
                        <Group>opendnssec</Group>
                </Privileges>

                <WorkingDirectory>/var/lib/opendnssec/tmp</WorkingDirectory>
        </Auditor>
</Configuration>

Then edit kasp.xml as follows:

<?xml version="1.0" encoding="UTF-8"?>
<!-- $Id: kasp.xml.in 3564 2010-07-06 13:39:29Z rb $ -->
<KASP>
        <Policy name="default">
                <Description>A default policy that will amaze you and your friends</Description>
                <Signatures>
                        <Resign>PT2H</Resign>
                        <Refresh>P3D</Refresh>
                        <Validity>
                                <Default>P7D</Default>
                                <Denial>P7D</Denial>
                        </Validity>
                        <Jitter>PT12H</Jitter>
                        <InceptionOffset>PT3600S</InceptionOffset>
                </Signatures>
                <Denial>
                        <NSEC3>
                                <!-- <OptOut/> -->
                                <Resalt>P100D</Resalt>
                                <Hash>
                                        <Algorithm>1</Algorithm>
                                        <Iterations>5</Iterations>
                                        <Salt length="8"/>
                                </Hash>
                        </NSEC3>
                </Denial>
                <Keys>
                        <!-- Parameters for both KSK and ZSK -->
                        <TTL>PT3600S</TTL>
                        <RetireSafety>PT3600S</RetireSafety>
                        <PublishSafety>PT3600S</PublishSafety>
                        <!-- <ShareKeys/> -->
                        <Purge>P14D</Purge>

                        <!-- Parameters for KSK only -->
                        <KSK>
                                <Algorithm length="2048">7</Algorithm>
                                <Lifetime>P1Y</Lifetime>
                                <Repository>SoftHSM</Repository>
                                <Standby>0</Standby>
                        </KSK>

                        <!-- Parameters for ZSK only -->
                        <ZSK>
                                <Algorithm length="1024">7</Algorithm>
                                <Lifetime>P150D</Lifetime>
                                <Repository>SoftHSM</Repository>
                                <Standby>0</Standby>
                                <!-- <ManualRollover/> -->
                        </ZSK>
                </Keys>
                <Zone>
                        <PropagationDelay>PT43200S</PropagationDelay>
                        <SOA>
                                <TTL>PT86400S</TTL>
                                <Minimum>PT1H</Minimum>
                                <Serial>unixtime</Serial>
                        </SOA>
                </Zone>
                <Parent>
                        <PropagationDelay>PT9999S</PropagationDelay>
                        <DS>
                                <TTL>PT3600S</TTL>
                        </DS>
                        <SOA>
                                <TTL>PT172800S</TTL>
                                <Minimum>PT10800S</Minimum>
                        </SOA>
                </Parent>
                <Audit>
                        <!-- <Partial /> -->
                </Audit>
        </Policy>
</KASP>

Edit the following file /etc/softhsm/softhsm.conf then add:

1:/var/lib/opendnssec/db/kasp.db

We can now create the database, it will ask for you PIN, this is the one declared in your first configuration file. Execute the following: softhsm –init-token –slot 1 –label “OpenDNSSEC”

Edit your groups file to match the following:

bind:x:107:opendnssec
opendnssec:x:114:bind
softhsm:x:999:opendnssec

You can now setup the database by doing the following: ods-ksmutil setup

I recommend doing the following to set permissions right and linking the new signed/unsigned directories for OpenDNSSEC.

chown -R opendnssec:opendnssec /var/lib/opendnssec/
chgrp opendnssec /etc/opendnssec/*
ln -s /var/lib/opendnssec/signed /etc/bind/master/
ln -s /var/lib/opendnssec/unsigned /etc/bind/master/

This is now the exciting bit, we are adding our first zone, copy it under /var/lib/opendnssec/unsigned then do:

ods-ksmutil zone add -z myzone.net
service opendnssec-enforcer restart
service opendnssec-signer restart

If you have done it right, it will tell you that it found your zone. If this is the case, it is now time to declare it in order to generate keys: ods-ksmutil key generate –policy default –interval 30. At this stage, you have to wait for the zone to become valid, this takes around 12h depending on what you setup. Time to make yourself a few coffees and listen to a few metal albums.

You now need to ready your zones. Rather than doing it manually, here is a script you can use (make sure you put it in the right folder):

ods-ksmutil  key list |grep ready|awk '{ print $1 }'  > list
for i in `cat list`;
do
SERIAL=`ods-ksmutil key export --zone $i --keystate ready |awk '{ print $11 }'`
ods-ksmutil key ds-seen -z $i -x $SERIAL
done

Now that the zone is ready, you need to get ods to sign it, this is just done by service opendnssec-signer restart. If it worked, you should see your new signed zone in /etc/bind/master/signed. All you got to do now is to change your bind config to point to the newly signed file.

We are now at the end of this article, it should be pointed out that keys expire, your Zone Signing Key (ZSK) expires after 6 months and the KSK after a year, you should plan for regenerating keys before the expiry if possible, since you are supposed to propagate these to the internet to establish the chain of trust from the root servers.

When you are modifying a zone, just trigger ods-signer sign myzone.net to re-sign it. If you need to delete a zone within ods, you can use the following: ods-ksmutil zone delete –zone myzone.net

At this time of writing please note that only a FEW root zones are signed, so this is more research than production (although all my zones are currently signed).

I have been using NGINX for a while and really like it. You run into special cases depending on when you are trying to run any CGI stuff. I wanted to quickly document how to get it running on a Debian system. I will assume you are using /var/www as your web root and you have Debian. It all starts with apt-get install gitweb fcgiwrap then you need to symlink your new install like this: ln -s /usr/share/gitweb /var/www/.

You now need to tell nginx what to do and how, edit your default file (or wherever you set your vhosts) then add this:

       location /gitweb/ {
		index index.cgi;
		include fastcgi_params;
                gzip off;

               if ($uri ~ "/gitweb/index.cgi") {
                        fastcgi_pass unix:/var/run/fcgiwrap.socket;
                }

        }

My fastcgi_params file is a bit different from the defaults, so I am adding this here, edit /etc/nginx/fastcgi_params

fastcgi_param  QUERY_STRING       $query_string;
fastcgi_param  REQUEST_METHOD     $request_method;
fastcgi_param  CONTENT_TYPE       $content_type;
fastcgi_param  CONTENT_LENGTH     $content_length;

fastcgi_param  SCRIPT_NAME        $fastcgi_script_name;
fastcgi_param  REQUEST_URI        $request_uri;
fastcgi_param  DOCUMENT_URI       $document_uri;
fastcgi_param  DOCUMENT_ROOT      $document_root;
fastcgi_param  SERVER_PROTOCOL    $server_protocol;

fastcgi_param  GATEWAY_INTERFACE  CGI/1.1;
fastcgi_param  SERVER_SOFTWARE    nginx/$nginx_version;

fastcgi_param  REMOTE_ADDR        $remote_addr;
fastcgi_param  REMOTE_PORT        $remote_port;
fastcgi_param  SERVER_ADDR        $server_addr;
fastcgi_param  SERVER_PORT        $server_port;
fastcgi_param  SERVER_NAME        $server_name;

# PHP only, required if PHP was built with --enable-force-cgi-redirect
fastcgi_param  REDIRECT_STATUS    200;

Just do a service nginx restart and point your browser to /gitweb, all set!
